Specification
Model Number
|
LRF-SE6
|
Laser Type
|
Solid State Laser
|
Laser Wavelength
|
1535nm±5nm (safe for human eyes)
|
Ranging Scope
|
30m-2km 3km 5km 8km
|
Ranging Resolution
|
0.1m
|
Ranging Accuracy
|
(0-2000M)≤±1m(RMS), (2000-8000M)≤±2m(RMS)
|
Input Voltage
|
DC5V
|
Laser Beams Divergence Angle
|
0.3 mrad
|
Measuring Frequency
|
1 Hz
|
Control Mode
|
Instruction set (Standard)
|
Communication Interface
|
UART (TTL 3.3V Standard)/Customized
|
UART Baud
|
9600bps
|
Dia. Receiver Aperture
|
32mm
|
Structure Material
|
Aluminum
|
Weight
|
138g±10g
|
Dimension
|
74X55X40mm
|
Operation temperature
|
From -40℃ to 65℃
|
Product Description
1. Features: Stable performance Strong adaptability to environment Customizable structure Broad Application in Various Areas Convenient use Flexible installation Easy integration
2. Application: Drone, Thermal Imaging System. Various distance measurement cases (Aviation, security, railway, electric power, water conservancy, communication, environment, geology, construction, agriculture, forestry, outdoor sport etc.)
3. Customized items: Ranging Scope, Communication Interface, Structure & Photoelectric system
